Small size elbow is curved connecting pieces that join straight lengths of pipe, commonly at a 90° or 45° angle, allowing obstructions to be avoided in plumbing, ventilation, welding, and automotive applications.

Small size elbow
Paint

We supply a full range of Small size elbow schedules ranging from SCH 5 thru Double Extra Heavy, we deliver Small size elbow with Exceptional sizes & Quality.

Sunny Steel is the most acclaimed manufacturer, exporter, distributor and supplier of industrial Small size elbow with required test certificates. You can also Order small quantities, we will be happy to quote best price for small and large quantities & can typically deliver the Small size elbow in minimum time frame anywhere around the globe.

Small size elbow is used to be installed between two lengths of pipe or tube allowing a change of direction, usually these carbon steel elbows distinguished by connection ends. The ends may be machined for butt welding , threaded , or socketed , so the carbon steel elbows are consist of butt weld, thread elbow socket elbow and other series. The material is selected according to the application use such as high temperature use, sanitary fitting, regular industrial use etc.



An elbow is a pipe fitting installed between two lengths of pipe or tubing to allow a change of direction, usually a 180° or 90° angle, though 45° elbows are also made. The ends may be machined for butt welding (SW) or socketed welding(SW) etc.

Most elbows are available in short radius or long radius variants. When the two ends differ in size, the fitting is called a reducing elbow or reducer elbow.

Elbows are categorized based on various design features as below:

Size range:

Elbow Size

Recommended type of pipe elbows:

Materials

  • Carbon steel: ASTM/ASME A234 WPB-WPC
  • Alloy steel: --WP 22-WP 5-WP 91-WP 911
  • Low temperature steel: ASTM/ASME A402 WPL 3-WPL 6
  • High performance steel: ASTM/ASME A860 WPHY 42-46-52-60-65-70
  • Stainless steel: ASTM/ASME A403 WP 304-304L-304H-304LN-304N
    • ASTM/ASME A403 WP 316-316L-316H-316LN-316N-316Ti
    • ASTM/ASME A403 WP 321-321H ASTM/ASME A403 WP 347-347H

Abrasion resistant elobw

SHS-self-propagating ceramic composite steel pipe and fittings, the new generation of wearable and corrosion resistant engineering pipeline, belongs to "863" Hi-tech Plan products.

It is the ideal wearable and corrosion resistant engineering pipeline, with wear resistance 15 times higher than common steel pipe, smooth inner surface, and favorable liquor resistance.

Pipe elbows

Butt Weld Pipe Fitting Bevel

  • All welded pipe fittings have bevelled end to allow for ease of welding.
  • This bevel allows for full penetration weld in most cases.
  • There are two types of bevels;
    Plain Bevel and Compound Bevel: according to the bevel of welding pipe fittings construction .
  • ASME B16.28, Buttwelding Short Radius Elbows and Returns
Industrial Processes: Bending, squeezing, pressing, forging, machining and more ANSI/ASME B16.25, Buttwelding Ends
ANSI/ASME B16.25 Standard covers the preparation of butt welding ends of piping components to be joined into a piping system by welding.

Application of pipe elbows:

Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc.

ELL & ELLS

  • A wing of a building at right angles to the main structure.
  • A right-angled bend in a pipe or conduit; an elbow.

Pipe elbows by radius and degree

We offer multiple bend pipes, all with different specs and operative requirements.

Short radius

SR Elbows have a Center-to-Face dimension of 1.0 X diameter usually includes three angles degree ( 45°,90°,180°).

Butt weld 5D pipe bend
Long radius

The radius of LR elbow curvature of is 1.5 times the diameter of the pipe, usally includes three degrees (45° ,90°,180°)

Reducing elbow

The reducing elbow eliminates one pipe fitting and reduces the welding by more than one-third.



Fitting specification, Standard and identification

There are different varieties of pipe fittings made of various materials and available in various shapes and sizes.



SUNNY STEEL

Our team are highly trained and experienced in servicing and producing all types of steel supplies. Whether you've got a large construction project, or need parts for industrial machinery, our team of steel fabrication consultants will ensure that your project is provided with the parts you need, when you need them.
