DIN17175/EN10216 standard specification

DIN 17175 steel pipes are used in boiler installations, high-pressure pipelines and tank construction and special machinery for both high temperature and high-pressure devices.
DIN 17175  Heat-resisting seamless steel tube

DIN 17175 Heat-resisting seamless steel tube

DIN 17175 alloy steel pipe is just a big class,and it has many classifivations. We mainly produce DIN 17175 ST35.8,DIN 17175 ST45.8, and 10CrMo910 steel pipes. This alloy steel pipe is just a big class,and it has many classifivations.

We mainly produce DIN 17175 ST35.8,DIN 17175 ST45.8, and 10CrMo910 steel pipes.

Main Steel grade:
Chemical Compositions of DIN 17175 steel pipes (%)
Grade C Si Mn P S Cr Mo
St35.8 ≤0.17 0.10-0.35 0.40-0.80 ≤0.040 ≤0.040 / /
St45.8 ≤0.21 0.10-0.35 0.40-1.20 ≤0.040 ≤0.040 / /
15Mo3 0.12-0.20 0.10-0.35 0.40-0.80 ≤0.035 ≤0.035 / 0.25-0.35
13CrMo44 0.10-0.18 0.10-0.35 0.40-0.70 ≤0.035 ≤0.035 0.70-1.10 0.46-0.65
10CrMo910 0.08-0.15 ≤0.50 0.40-0.70 ≤0.035 ≤0.035 0.20-0.25 0.90-1.20
Mechanical Properties of DIN17175 steel pipe
Grade Yield Strength (Mpa) Tensile Strength (Mpa) Elongation(%)
St35.8 ≥235 360-480 25
St45.8 ≥255 410-530 21
15Mo3 ≥275 450-600 20
13CrMo44 ≥290 440-590 20
10CrMo910 ≥280 450-600 18
Packing:
Read more:

DIN: Deutsche Industrie Normen (=German Industry Standard)

DIN 17175-79 seamless steel tubes for elevated temperatures (DIN17175)

Sections marked with a dot(●) contain details on agreements which shall, or may be, reached at the time of ordering.

Grade Mfg. Process Chemical composition(%)
C Si Mn P S Ni Cr Mo Others
St35.8 S 0.17Max 0.10-0.35 0.40-0.80 0.040Max 0.040Max - - - -
St45.8 S 0.21Max 0.10-0.35 0.40-1.20 0.040Max 0.040Max - - - -
17Mn4 S 0.14-0.20 0.20-0.40 0.90-1.20 0.040Max 0.040Max - 0.30Max - -
19Mn5 S 0.17-0.22 0.30-0.60 1.00-1.30 0.040Max 0.040Max - 0.30Max - -
15Mo3 S 0.12-0.20 0.10-0.35 0.40-0.80 0.035Max 0.035Max - - 0.25-0.35 -
13CrMo910 S 0.10-0.18 0.10-0.35 0.40-0.70 0.035Max 0.035Max - 0.70-1.10 0.45-0.65 -
10CrMo910 S 0.08-0.15 0.50Max 0.40-0.70 0.035Max 0.035Max - 2.00-2.50 0.90-1.20 -
14MoV63 S 0.10-0.18 0.10-0.35 0.40-0.70 0.035Max 0.035Max - 0.30-0.60 0.50-0.70 V : 0.22-0.32
X20CrMoV121 S 0.17-0.23 0.50Max 0.40-0.70 0.030Max 0.030Max 0.30-0.80 10.00-12.50 0.80-1.20 V : 0.25-0.35
Grade   Materia number Tensile Test MPa or N/mm2 Remaks(Similar to JIS) Possibility Temperature
Min Yield point Tensile Strength
t 16Max 16<t 40Max
St35.8 1.0305 235 225 360-480 Impact Test at Room Temp.kgf-m
(STPT38)


St45.8 1.0405 - 245 410-530 23.5(STPT410, STB410)
17Mn4 1.0481 - 275 460-580 22.8
19Mn5 1.0482 - 315 510-610 23.5(STB52)
15Mo3 1.5415 275 275 450-600 23.5
13CrMo910 1.7335 295 295 440-590 23.2(STPA22, STBA22)
10CrMo910 1.7380 285 285 450-600 23.2(STPA24, STBA24)
14MoV63 1.7715 325 325 460-610 24.2
X20CrMoV121 1.4922 490 490 690-850 23.5
1. Scope

This standard applies to seamless tubes 1) including tubes for headers of heat-resistant steels according to Table 1 which are used in the construction of boilers, pipe-lines, pressure vessels and equipment for service up to 600∩ and at simultaneous high pressures, where the tototal stress and the relevant scaling conditions can raise or lower the temperature limit.

5. Designation and ordering

5.1. The code numbers for the grades of steel were formed in accordance with Sections 2.1.1.1. and 2.1.2.2 of the Explanations to DIN Normenheft 3, and the material numbers according to DIN 17 007 Part 2.

5.2. The code number or the material number for the steel grade shall be appended to the symbol for the product according to the following examples :

Example 1:

Designation of a seamless steel tubes of 38mm outside diameter and 2.6mm wall thickness according to DIN 2448 of steel St 35.8, material number 1.0385 :

Tabe DIN 2448 - sT 35.8 x 2.6

or Tabe DIN 2448 - 1.0305 - 38 x 2.6

5.3. The order shall not only specify the designation according to Section 5.2 but also in every case the desired total length and the desired acceptance inspection certificate and for unalloyed steel tubes also the steel grade. In addition, further details in compliance with the other Sections marked with a dot(≤) can be agreed at the time of ordering.

DIN 8528 Part 1 Weldability; metallic materials, definitions

Table1.

Summary of heat-resisting steels for seamless tubes, their chamicalcomposition (cast analysis) and colour designation of tubes

Steel grade
Chemical composition in weight %
Code number
Material
number
C
Si
Mn
P
S
Cr
Mo
Ni
V
Colour
designa-
tion 1)
St 35.8
1.0306
÷ 0.17
0.10 to 0.35 2)
0.40 to 0.80
0.040
0.040
white
St 45.8
1.0406
÷ 0.21
0.10 to 0.35 2)
0.40 to1.20
0.040
0.040
yellow
17Mn 4 3)
1.0481 3)
0.14 to 0.20
0.20 to 0.40
0.90 to 1.20
0.040
0.040
÷ 0.30
red
and
black
19Mn 5 3)
1.0482 3)
0.17 to 0.22 4)
0.30 to 0.60
1.00 to 1.30
0.040
0.040
÷ 0.30
yellow
and
brown
15Mn 3
1.5415
0.12 to 0.20 4)
0.10 to 0.35
0.40 to 0.80
0.035
0.035
0.25 to 0.35
yellow
and
carmine
red
13CrMo 4 4
1.7335
0.10 to 0.18 4)
0.10 to 0.35
0.40 to 070
0.035
0.035
0.70 to 1.10
0.45 to 0.65

yellow
and
shades or
silver

10CrMo 9 10
1.7380
0.08 to 0.15
÷ 0.50
0.40 to 070
0.035
0.035
2.00 to 2.50
0.90 to 1.20
red
and
green
14MoV 6 3
1.7715
0.10 to 0.18
0.10 to 0.35
0.40 to 0.70
0.035
0.035
0.30 to 0.60
0.50 to 0.70
0.22 to 0.32
red
and
shades
of silver
X20CrMoV 12 1
1.4922
0.17 to 0.23
÷ 0.50
÷ 1.00
0.030
0.030
10.00 to 12.50
0.80 to 1.20
0.30 to 0.80
0.25 to 0.35
blue
Table 2.

Permissible deviations in the chemical composition of the sample analysis from the limits quoted in the cast analysis (see Table 1)

Element Limits quoted in cast analysis
according to Table 1

Weight %
Permissible deviation 1)
of sample analysis from the
limits quoted in the cast
analysis according to Table 1

Weight %
C ÷0.24 【 0.02
Si ÷0.35
>0.35÷0.60
【 0.03
【 0.04
Mn ÷1.00
>1.00÷1.30
【 0.04
【 0.05
P
S
÷0.040

【 0.010
Cr ÷0.040÷2.00
>2.00÷2.50
∶1.00÷12.50
【 0.05
【 0.07
【 0.15
Mo ÷0.30
>0.30 ÷1.20
【 0.03
【 0.04
Ni 0.30÷0.80 【 0.03
V 0.22÷0.35 【 0.03
1) In a cast the deviation of an element of an elemcnt in a sample analysis is permitted to be below the minimum value or only above the maximum value of the range stipulated for the cast analysis, though not both at the same time.
Table 3. Scope of tests for seamless tubes in both quality grades and authority for the execution of the testings.
No Extent of testing According
to Section
Quality grade I Quality grade II Authority for the execution of the test 1)
1 Tensile test 2) 8.4.3 on two tubes per batch from the first two batches, on one tube from each subsequent batch on two tubes per batch from the first two batches, on one tube from each subsequent batch S.A.
2 Notch impact/bending test 3) 8.4.4

on tubes according to No.1

on tubes according to No.1 S.A.
3 Ring test 3) 8.4.6 on one end of the tubes acc to No.1 depending on the diameter (see Section 8.4.6) on 20% of the cut or part-lengths at one end or on 100% of the cut or part-lengths at both ends if necessary though also at one end, see Section 8.4.6.2.2. M.W.
4 Non-destructive test 8.4.7 all tubes M.W.
5 Visual inspection of tube surface 8.4.8 all tubes all tubes S.A.
6 Gauging 8.4.9 all tubes all tubes M.W.

7 Leakage test 8.4.10 all tubes all tubes M.W.
8 Grade identification test 8.4.11 all alloy tubes M.W
9 Special tests 4)
No. 9, No. 10
8.4.2 subject to agreement subject to agreement. M.W
10 Hot tensile test 8.4.5 unless otherwise agreed 1 sample per cast and size or 1 sample per cast and annealed batch (heattreated batch) unless otherwise agreed 1 sample per cast and size or 1 sample per cast and annealed batch (heattreated batch) S.A.

1) S.A = subject to agreement; M.W. = Manufacturing works.

2) 1 specimen or 1 set of specimens suffices for batch sizes of up to 10 tubes.

3) The particulars on the size range governing the application of these test in Table 14 shall be complied with.

4)≤ Special tests shall be carried out only after agreement between manufacturer and customer.

Table 4. Limits governing the application of quality grades I and III
Quality Outside diameter of tube
÷ 63.5mm > 63.5mm
Temperature 2)
Permissible
working
pressure 3)
bar
Temperature 2)
Permissible
working
pressure 3)
bar
I ÷ 450 ÷ 80 ÷ 450 ÷ 32
III > 450 > 80 > 450 > 32

1) If pressure and temperature data do not belong to the same group, the higher group applies.

2) Temperature of conveyed fluid.

3) See DIN 2401 Part 1

Table 5. Mechanical properties of seamless of heat-resistant steels at room temperature
Steel grade Tensile
strength

N/С
Yield point 1), 2)
for wall thickness
in mm
Elongation at
fravture
(Lo = 5*do)
Impact strength
(DVM specimens 3)
transverse
J
minimum
Code
number
Material
number
÷16 >16÷40 >40÷50 Long Trans-
verse
N/С
minimum
%
minimum
St 35.8 1.0305 360 to 480 235 225 215 25 23 34
St 45.8 1.0405 410 to 530 255 245 235 21 19 27
17 Mo 4 1.0481 460 to 580 270 270 260 23 21 34
19 Mo5 1.0482 510 to 610 310 310 300 19 17 34
15 Mo 3 1.5415 450 to 600 270 4) 270 260 22 20 34
13CrMo 4 4 1.7335 440 to 590 290 4) 290 280 22 20 34
10CrMo 9 10 1.7380 450 to 600 280 280 270 20 18 34
14MoV 6 3 1.7715 460 to 610 320 320 310 20 18 41
X20CrMoV 12 1 1.4922 690 to 840 490 490 490 17 14 34 5)

1) For tubes of ÷ 30mm outside diameter and ÷ 3mm wall thickness the minimum values are by 10N/П lower.

2) For > 60mm wall thickness, the values of tubes from the steels St 35.8, St 45.8, 17Mn 4, 19Mn 5, 15Mo 3 and 14MoV 6 3 are subject to agreement; for wall thicknesses >60 to ÷ 80mm a minimum value of 270N/П or 260N/П applies fot tubes from the steels 13CrMo 4 4 and 10CrMo 9 10 and a minimum value of 490N/П for tubes from the steel X20CrMoV 12 1.

3) When testing longitudinal specimens (see Section 8.5.3) theminimum impact strength is 14J higher.

4) A 15N/П higher minimum value applies for ÷ 10mm wall thicknesses.

5) For hot extruded tubes the minimum value falls to 27J.

Table 6. Minimum 0.2% yield limit of seamless tubes at elevated temperatures.
Steel grade Wall thickness
s
mm
0.2%-yield limit
at
Code number Material number 200∩ 250∩ 300∩ 350∩ 400∩ 450∩ 500∩ 550∩
N/П
minimum
St 35.8 1.0305 ÷ 16
16<s÷40
40<s÷60 1)
185
180
175
165
160
155
140
135
130
120
120
115
110
110
110
105
105
105
-
-
-
-
-
-
St 45.8 1.0405 ÷ 16
16<s÷40
40<s÷60 1)
205
195
190
185
175
170
160
155
150
140
135
135
130
130
130
125
125
125
-
-
-
-
-
-
17Mn 4 3) 1.0481 ÷ 40
40<s÷60 1)
235
225
215
205
175
165
155
150
145
140
135
130
-
-
-
-
19Mn 5 3) 1.0482 ÷40
40<s÷60 1)
255
245
235
225
205
195
180
170
160
155
150
145
-
-
-
-
15Mn 3 1.5415 ÷40 2)
40<s÷60 1)
225
210
205
195
180
170
170
160
160
150
155
145
150
140
-
-
13CrMo 4 4 1.7335 ÷ 40 2)
40<s÷60
60<s÷80 1)
240
230
220
230
220
210
215
205
195
200
190
180
190
180
170
180
170
160
175
165
155
-
-
-
10CrMo 9 10 1.7380 ÷ 40
40<s÷60
60<s÷80 1)
245
235
225
240
230
220
230
220
110
215
205
195
205
195
185
195
185
175
185
175
165
-
-
-
14MoV 6 3 1.7715 ÷ 40
40<s÷60 1)
270
260
255
245
230
220
215
205
200
190
185
175
170
160
-
-
X20CrMoV 12 1 1.4922 ÷ 80 430 415 390 380 360 330 290 250

1) For wall thicknesses greater than 60mm the values are subject to agreemnet.

2) For wall thicknesses ÷ 10mm, 15 N/С higher minimum 0.2% yield limits apply at all temperatures.

Table 7. Provisional data 1) (change in diameter) in the ring expending test.
Steel grade Expansion 2) in ring expanding test (provisional data)
For diameter ratios di/da
∶ 0.9 ∶ 0.8
< 0.9
∶0.7
< 0.8
∶ 0.6
< 0.7
∶ 0.5
< 0.6
< 0.5
%
minimum
unalloyed steels 8 10 12 20 25 30
alloyed steels 6 8 10 15 20 30

1) These values shall regarded as initial recommendations which are based on a series of tests and will have to be reassessed in the light of future experience.

2) The deformability of ring expanding test specimens will additionally be assessed in terms of the appearance of the fracuture and fracture surfaces.

Table 8. Permissible wall thickness deviations for orders based on the outside diameter
Perttissible wall thickness deviations for outside diameters da
da ÷ 130mm 130mm <da ÷ 320 mm 320mm <da ÷ 660mm
÷2*Sn ÷2*Sn<s÷4*Sn >4*Sn ÷0.05da ÷0.05da<s÷0.11da >0.11da ÷0.05da 0.05da<s÷0.09da >0.09da
+15%
-10%
+12.5%
-10%
【9% +17.5%
-12.5%
【12.5% 【10% +22.5%
-12.5%
+15%
-12.5%
+12.5%
-10%
Note : Sn = Norninal wall thickness according to DIN 2448
Table 9. Permissible wall thickness deviations for orders based on the bore
Pernissible wall thickness deviations for inside diameter di ∶ 200mm to ÷ 720mm and waill thicknesses s
÷ 0.05da 0.05<s÷0.10da >0.10 da
+22.5%
-12.5%
+15%
-12.5%
+12.5%
-10%
Table 10. Permissible deviations on length
For orders specifying Permissible
deviations on length
in mm
Productino lengths 1)
Random lengths 【 500
Exact lengths 【 10
0
from ÷ 6m (norninal size)
from > 6m ÷ 12m (norninal size) 【 15
0
from > 12m subject to agreement
1) The products are supplied in production lengths which differ according to diameter, wall thickness and production plant.
Table 11. Permissible deflection
b in mm ÷ 100 >100÷ 200 >200÷ 300 > 300
f in mm ÷ 0.75 ÷ 1 ÷ 1.5 ÷ 2
Table 12. Reference data for hot forming, normalising and hardening and tempering of high-temperature seamless tube steels 1)
Steel grade Hot forming

Normalising

Hardening and tempering
Code number Material
number
Hardeing
temperature 2)
Tempering
temperature
St 35.8 1.0305 between 1100
and 850 3)
900 to 930 - -
St 45.8 1.0405 870 to 900 - -
17Mn 4 3) 1.0481 880 to 910 - -
19Mn 5 3) 1.0482 880 to 910 - -
15Mn 3 1.5415 910 to 940 - -
13CrMo 4 4 1.7335 - 910 to 940 660 to 730
10CrMo 9 10 1.7380 - 900 to 960 700 to 750
14MoV 6 3 1.7715 - 950 to 980 690 to 730
X20CrMoV 12 1 1.4922 - 1020 to 1070 730 to 780

1) The work pieces must attain the specified temperature over the entire cross-section. Provided this has definitely been done further holding at these temperatures is unnecessary when normalising and hardeing.

The temperatures laid down for tempering shall be held for approximately 30minutes minimum for the steels 13CrMo 4 4 and 10CrMo 9 10 and for 1 hour minimum for the steels 14MoV 6 3 and X20CrMoV 12 1, with the annealing time being countedfrom the momentwhen the lower limit of the given temperature range is reached.

2) Cooling in air or controlled atmosphere. Accelerated cooling e.g in liquid, can become necessary at greater wall thicknesses.

3) The temperature can drop to 750∩ during processing.

4) In addition to given quenching and tempering treament the following sequenece of treatment can be considered for the stee :

900∩ to 960∩/furnace to 700∩ ∶1 hour 700∩/air.

Table 13. Welding methods and data for the heat-treatment after welding
Steel grade Welding methods Annealing temperatures 1)
and holding time 2), 3)
at the required heat-treatment
after welding
Code number Material
number
St 35.8 1.0305 All fusion welding methods
and flash butt-welding
520 to 600
St 45.8 1.0405 520 to 600
17Mn 4 3) 1.0481 520 to 580
19Mn 5 3) 1.0482 520 to 580
15Mn 3 1.5415 530 to 620
13CrMo 4 4 1.7335 600 to 700
10CrMo 9 10 1.7380 650 to 750
14MoV 6 3 1.7715 All fusion welding methods,
except gas fusion welding
690 to 730
X20CrMoV 12 1 1.4922 720 to 780

1) If required (see Section 7.3) these temperatures apply also to annealing treatments after cold forming.

2) The holding time for the specified temperatures depends on the thickness of the workpieces. A minimum holding time of 15minutes is recommended for a thickness ÷15mm, a minimum holding time of 30minutes, for thicknesses > 15 to÷30mm and a minimum holding time of 60minutes for thicknesses >30mm.

At thicknesses >30mm a minimum holding time of 90 minutes is required for 10CrMo 9 10. Furnace anneals should be performed in the mid-range of the specified temperatures. For local anneals the external surface shall be at the maximum temperature.

3) The annealing treatment shall also comply with the instructions f the manufacturer of the filier metals.

4) Judging from the experience gained up t nw, repeated annealing treatments shall not exceed a total holding time of 10 hours, with the subsequent annealing treatments being performed in the lower temperature range when the material is in the air-hardaned condition.

5) Welding shall be followed by cooling below 150∩ (though for thick-walled tubes not below 100∩).
The following holding times are recommended :

÷8mm thickness 30minutes minimum
>8÷30mm thickness 60minutes minimum
>30÷60mm thickness 120minutes minimum
>60mm thickness 180minutes minimum

Table 14. Size ranges for the application of mechanical and technological methods for testing tubes in both qualities
Tube diameter
mm
Norminal wall thickness of the tubes
external internal <2mm ∶2mm÷16mm >16mm÷30mm >30mm÷40mm >40mm
÷21.3 ÷15 Tensile test
Ring flattening
test
Tensile test
Ring flattening
test
- - -
> 21.3 ÷ 148 >15 Tensile test
Ring flattening
test
Tensile test
Notch
impact/bending
test 1)
Ring expanding
test
Tensile test
Notch
impact/bending
test 1)
Ring expanding
test
Tensile test
Notch
impact/bending
test 1)
Ring expanding
test
Tensile test
Notch
impact/bending
test 1)
Ring expanding
test
> 146 3)

Tensile test
Notch
impact/bending
test 1)
Ring tensile test
Tensile test
Notch
impact/bending
test 1)
Ring tensile test 2)
Tensile test
Notch
impact/bending
test 1)
Ring tensile test 2)
Tensile test
Notch
impact/bending
test

1) Only for tubes manufactuered from steels 14MoV 6 3 and X20CrMoV 12 1 in nominal thicknesses > 10mm and for tubes manufactuered from steel 15Mo 3 in nominal thicknesses >20mm.

2) Tubes ÷ 100mm inside diameter shall bering flattening-tested instead of ring tensile-tested.

3) This limit applies also for tube, orders for which are based on the inside diameter, provided the nominal outside diameter > 146mm.

Appendix A
The following Table gives tentative figures for the ong time high teme high temperature strength of the steels used for seamless tubes. The figures listed are mean values for the scatter ranger representing results so far available. These mean values will be examined from time to time and amended where necessary as further results become available. From the data so far available from long time creep tests it can be assumed that the bottom limit of this scatter range at the stated temperatures for the steel grades listed is about 20% lower than the mean value quoted.
Table A.1.
Steel grade

Code number
Temperature

1%-time yield limit 1), 2) Creep strength 2),3)
for
10 000h
N/П
100 000h
N/П
10 000h
N/П
100 000h
N/П
200 000h
N/П
St 37.8
St 42.8

380
390
164
150
118
106
229
211
165
148
145
129
400
410
420
430
440
136
124
113
101
91
95
84
73
65
57
191
174
158
142
127
132
118
103
91
79
115
101
89
78
67
450
460
470
480
80
72
62
53
49
42
35
30
113
100
86
75
69
59
50
42
57
48
40
33
17Mn 4
19Mn 5
380
390
195
182
153
137
291
266
277
203
206
181
400
410
420
430
440
167
150
135
120
107
118
105
92
80
69
243
221
200
180
161
179
157
136
117
100
157
135
115
97
82
450
460
470
480
490
93
83
71
63
55
59
51
44
38
33
143
126
110
96
84
85
73
63
55
65
47
70
60
52
44
37
500 49 29 74 41 30
15 Mo 3 450
460
470
480
490
216
199
182
166
149
167
146
126
107
89
298
273
247
222
196
245
209
174
143
117
228
189
153
121
96
500
510
520
530
540
132
115
99
84
(70)
73
59
46
36
(28)
171
147
125
102
(82)
93
74
59
47
(38)
75
57
45
36
(28)
550 (59) (24) (64) (31) (25)

1) This being the stress referred to the original cross-section which leads to a permanent elongation of 1% after 10000 or 100000 hours (h).

2) A bracket denotes that the steel should preferably no longer be used for continuous service t the relevant temperature.

3) This being the stress referred to in the original cross-section which results in rupture after 10 000, 100 000 or 200 000 hours (h).


Table A.1. (continued)
Steel grade

Code number
Temperature

1%-time yield limit 1), 2) Creep strength 2),3)
for
10 000h
N/П
100 000h
N/П
10 000h
N/П
100 000h
N/П
200 000h
N/П
13CrMo 4 4 450
460
470
480
490
245
228
210
193
173
191
172
152
133
116
370
348
328
304
273
285
251
220
190
163
260
226
195
167
139
500
510
520
530
540
157
139
122
106
90
98
83
70
57
46
239
209
179
154
129
137
116
94
78
61
115
96
76
62
50
550
560
570
76
64
53
36
30
24
109
91
76
49
40
33
39
32
26
10CrMo 9 10

450
460
470
480
490
240
210
200
180
163
166
155
145
130
116
306
286
264
241
219
221
205
188
170
152
201
186
169
152
136
500
510
520
530
540
147
132
119
107
94
103
90
78
68
58
196
176
156
138
122
135
118
103
90
78
120
105
91
79
68
550
560
570
580
590
83
73
65
57
50
49
41
35
30
26
108
96
85
75
68
68
58
51
44
38
58
50
43
37
32
600 44 22 61 34 28
14MoV 6 3 480
490
243
219
177
155
299
268
218
191
182
163
500
510
520
530
540
195
178
161
146
133
138
122
107
94
81
241
219
198
179
164
170
150
131
116
100
145
127
109
91
76
550
560
570
580
120
109
(98)
(88)
69
59
(48)
(37)
148
134
(121)
(108)
85
72
(59)
(46)
61
48
(37)
(28)

For footnotes 1), 2) and 3) see page 18

Table A. 1.(continued).
Steel grade

Code number
Temperature

1%-time yield limit 1), 2) Creep strength 2),3)
for
10 000h
N/П
100 000h
N/П
10 000h
N/П
100 000h
N/П
200 000h
N/П
X20CrMoV 12 1 470
480
490
324
299
269
260
236
213
368
345
319
309
284
260
285
262
237
500
510
520
530
540
247
227
207
187
170
190
169
147
130
114
294
274
253
232
213
235
211
186
167
147
215
191
167
147
128
550
560
570
580
590
151
135
118
103
90
98
85
72
61
52
192
173
154
136
119
128
112
96
82
70
111
96
81
68
58
600
610
620
630
640
75
64
53
44
36
43
36
30
25
20
101
87
73
60
49
59
50
42
34
28
48
40
33
27
22
650 29 17 40 23 18
Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

A 106- Seamless C-Steel Pipe for High Temperature Service

ASTMSTANDARD UNS NO. KOREA/JAPANES GERMAN BRITISH BELGIAN FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number
Materiral

Number
Remarks B.S

Number
B.S Grade Remarks NBN Type NBN Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
Grade A K02501 SPHT 38 / STPT 370 D3570 / G3456 (16)(30) St 35.8 17175 1.0305 3602 HFS 360 D 37-2 629 (3b)(9) TU 37C A49-213 C 14 5462
Grade B K03006 SPHT 42 / STPT 410 D3570 / G3456 (16)(30) St 45.8 17175 1.0405 3602 HFS 410 D 42-2 629 (3b)(9) TU 42C A49-213 C 18 5462
Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

ASTMSTANDARD: A 179 - Seamless Cold Drawn Low-C Steel Heat Exchanger and Conderser Tubes

UNS NO. KOREA/JAPANES GERMAN BRITISH BELGIAN FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number
Materiral

Number
Remarks B.S

Number
B.S Grade Remarks NBN Type NBN Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
K01200 STBH 340 / STB 35 D3563 / G3461 St 35.4 1629

1.0309

3606 CFS 320 D 37-2 629 (3b) TU 37 C A49-215 (3a) C 14 5462
St 35.8 17175 1.0305 Plus DIN 2391 (18) Gutegard C.NBK

Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

ASTMSTANDARD: A 192 -Seamless C-Steel Boiler Tube for High Pressure Service

UNS NO. KOREA/JAPANES GERMAN BRITISH BELGIAN FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number
Materiral

Number
Remarks B.S

Number
B.S Grade Remarks NBN Type NBN Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
K01201 STBH 340 / STB 340 D3563 / G3461 (30) St 35.8 17175 1.0305 3059 320 (27)(30) D45 837 (27) TU 37C A49-213 (27) C14 5462

(27)


Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

A 199 - Seamless Cold Drawn Intermediate Alloy Steel Heat Exchange and Condenser Tubes

ASTMSTANDARD UNS NO. KOREA/JAPANES GERMAN BRITISH BELGIAN FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number
Materiral

Number
Remarks B.S

Number
B.S Grade Remarks NBN Type NBN Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
T5 K41545 STHA 24 / STBA 25 D3572 / G3462 (35) 12 CrMo 19 5 1.7362 (3a) 3606 CFS 625 (35) X 12 Cr Mo 5 837 (35) Z 12 CD 5.05 (3a) (3); dalmine 234
T11 K11597 STHA 22 / STBA 23 D3572 / G3462 (35) 13 CrMo 44 17175 1.7335 (8) 3606 CFS 621 (35) 10 CD 5.05 (3a) (3); dalmine 227(10)
T22 K21590 STHA 23 / STBA 24 D3572 / G3462 (35) 10 CrMo 9 10 17175 1.7380 3606 CFS 622 (35) 10 Cr Mo 9 10 837 (35) 10 CD 9.10 (3a) 12CrMo 9 10 5462 (10)0

Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

A 200- Seamless Intermediate Alloy Steel Still Tubes for Refinery Service

ASTMSTANDARD UNS NO. KOREA/JAPANES GERMAN BRITISH BELGIAN FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number
Materiral

Number
Remarks B.S

Number
B.S Grade Remarks NBN Type NBN Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
T 5 K41545 STHA 24 / STBA 25 D3572 / G3462 (32) 12 CrMo 19 5 1.7362 (3a) 3604 625

(30)(32)

X12CrMo 837 (32) TU Z 12 CD A49-213 (32) Dalmine 234(3b)
T 11 K11597 STHA 22 / STBA 23 D3572 / G3462 (32) 13 CrMo 44 17175 1.7335 (8) 3604 621 (30)(32) 5.05 A49-213 (32) Dalmine 227(3b)
T 22 K2159 STHA 23 / STBA 24 F3572 / G3462 (32) 10 CrMo 9 10 17175 1.7380 3606 622 (30)(32) 10 CrMo 9 10 837 (32) TU 10 CD 5.05 A49-213 (32) 12CrMo 9 10 5462 (3b)
TU 12 CD 9.10
Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

A 210 - Seamless Medium-Carbon Steel Boiler and Superheater Tubea

ASTMSTANDARD UNS NO. KOREA/JAPANES GERMAN BRITISH BELGIAN FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number
Materiral

Number
Remarks B.S

Number
B.S Grade Remarks NBN Type NBN Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
Grade A-1 K02707 STHA 410 / STB 410 D3563 / G3461 (30)(24) St 45.8 17175 1.0405 3059 320 (30) D45 837 (13) TU A42-C A49-213 (6)(13) C 18 5462 (38)
Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

A 213 - Seamless Alloy Steel Boiler and Heat Exchanger Tubes

ASTMSTANDARD UNS NO. KOREA/JAPANES GERMAN BRITISH FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number
Materiral

Number
Remarks B.S

Number
B.S Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
Grade T 5 K41545 STHA 24 / STBA 25 D3572 / G3462 (30)(24) 12 CrMo 19 5 1.7362 (3a) 3606 625 (30) TUZ12C A49-213 (3a)(32) Dalmine 234(3b)
Grade T 11 K11597 STHA 22 / STBA 24 D3572 / G3462 (30)(24) 13 CrMo 44 17175 1.7335 (8)(32) 3606 621 (30) 5.05 (3b)(32)

Dalmine 227(3b)

Grade T 12 K11562 STHA 21 / STBA 22 D3572 / G3462 (30)(24)

13 CrMo 44

17175 1.7335 (32) 3606 620 (30) TU 10 CD 5.05
Grade T 22 K21590 STHA 23 / STBA 24 D3572 / G3462 (30)(24) 10 CrMo 9 10 17175 1.7380 (32) 3606 622 (30)(32) (3a)(32) 12 CrMo 9 10 5462 Dalmine 235(3b)
TP 304 S30400 STS 304 TB / SUS 304 TB D3577 / G3463 (30)(24) X5 CrNi 18 9 17440 1.4301 (3b) 3606 304S25 (30) TU 10 CD 9.10 A49-218 (3b) X5 CrNi 18 10 6904 (3b)
TP 304L S31403 STS 304LTB / SUS 304LTB D3577 / G3463

(30)(24)

X2 CrNi 18 9 17440 1.4306 (3b) 3606 304S22 (30) Z 6 CN 18.09 A49-218 (3b) X2 CrNi 18 11 6904 (3b)
TP 310 S31000 STS 310STB/SUS 210STB D3577 / G3463 (30)(24) X12 CrNi 2528 1.4845

WBL-470(3b)

(3) Z 2 CN 18.09 (3) X22CrNi 25 20 6904 (3b)(11)
TP 316 S31600 STS 316TB / SUS 316TB D3577 / G3463 (30)(24) X5 CrNiMo 18 10 17440 1.4401 (3b) 3606 316S30 (30) A49-218 (3b) X5 CrNiMo 17 12 6904 (3b)
TP 316L S211603 STS 316LTB /SUS 316LTB D3577 / G3463 (30)(24) X2 CrNiMo 18 10 17440 1.4404 (3b) 3606 316S29 (30) Z 6 CND 17.12 A49-218 (3b) X2 CrNiMo 17 12 6904 (3b)
TP 321 S32100 STS 312TB/SUS 321TB D3577 / G3463 (30)(24) X10 CrNiTi 18 9 17440 1.4541 (3b) 3606 321S22 (30) Z2 CND 17.13 A49-218 (3b) X6 CrNiTi 18 11 6904 (3b)
TP 347 S34700 STS 347TB / SUS 347TB D3577 / G3463 (30)(24) X10 CrNiNb 18 9 17440 1.4550 (3b) 3606 347S17 (30) Z6 CNT 18.11 A49-218 (3b) X6 CrNiNb 18 11 6904 (3b)
Z 6 CNNb 18.11
Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

A 335 - Seamless Ferritic Alloy Steel Pipe for High Temperaure Service

ASTMSTANDARD UNS NO. KOREA/JAPANES GERMAN BRITISH FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number
Materiral

Number
Remarks B.S

Number
B.S Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
P1 K11522 SPA 12 / STPA 12 D 3573 / G 3458 (16) 16 Mo 5 1.5423 (3a) (3) TU 15 D 3 A49-213 16 Mo 5 5462
P5 K41545 SPA 25 / STPA 25 D 3573 / G 3458 (16) 12 CrMo 19 5 1.7362 WBL-590(3b) 3604 FHS 625 CAT.2 TU Z12 CD 5-05 A49-213 Dalmine234(3b)
P9 S50400 SPA 26 / STPA 26 D 3573 / G 3458 (16) (3) HFS 629-470 CAT.2 TU Z 10 CD 9 A49-213
P11 K11597 SPA 23 / STPA 23 D 3573 / G 3458 (16) 13 CrMo 44 17175 1.7335 (8) 3604 HFS 621 CAT.2 TU 10 CD 5.05 A49-213 Dalmine227(3b)
P12 K44562

SPA 22 / STPA 22

D 3573 / G 3458 (16) 13 CrMo 44 17175 1.7335 3604 HFS 620-440 CAT.2 (3) 14 CrMo 3 5462 (3b)
P22 K21590 SPA 24 / STPA 24 D 3573 / G 3458 (16) 10 CrMo 9 10 17175 1.7380 3604 HFS 622 CAT.2 TTU 10 CD 9.10 A49-213 12 Cr Mo 9 10 5462 (3b)
JIS Number and Corrensponding Foreign Standards
JIS ASTM BS DIN NF ISO Index Number
Standard Number Grade Tupe Standard Number Grade Tupe Standard Number Grade Tupe Standard Number Grade Tupe Standard Number Grade Tupe Standard Number Grade Tupe
G3456 STPT370
(STPT38)

C A106 GrA C 3602 HFS360 C 17175 St35.8 C A49-211 TU37b C 2604/2 TS5 C C004
" CFS360 C 17177 St37.8 C A49-213 TU37c C 2604/3 TW9H C
" ERW360 C A49-243 TU37c C
" CEW360 C
STPT410
(STPT42)



C A106 GrB C 3602 HFS410 C 17175 St45.8 C A49-211 TU42b C 2604/2 TS9H C
" CFS410 C 17177 St42.8 C A49-213 TU42c C
" ERW410 C A49-243 TU42c C
" CEEW410 C
STPT480
(STPT42)
C A106 GrC C 3602 HFS460 C A49-211 TU48b C 2604/2 TS14 C
" CFS460 C A49-213 TU48c C
" ERW460 C
" CEEW460 C


Seamless pipe Specification, standard and identification

Seamless pipes are extensively applied for the nuclear device, gas, petrochemical, ship building and boiler industries. Seamless pipes dominates 65% of market share in Chinese boiler industry.



SUNNY STEEL

Our team are highly trained and experienced in servicing and producing all types of steel supplies. Whether you've got a large construction project, or need parts for industrial machinery, our team of steel fabrication consultants will ensure that your project is provided with the parts you need, when you need them.

Link exchange

Copyright © 2011 Sunny Steel Enterprise Ltd.  All Rights Reserved ICP No.:08010763
